Case

 80mm, Black Steel and chrome bezel

Connection

Bottom Entry

Window

 Clear Plastic

Pointer

 Black aluminium with loose red pointer

Filling

 Dry

Working Pressure

 Steady,75% full scale range

Fluctuating

 60% full scale range

Short Time

 full scale range

Operating Temperature

 Ambient:-20 to +60°C

Medium

 -20 to +60°C

Storage Temperature

 -40 to +60°C

Temperature Effect

 When temperature of the pressure element deviates from reference temperature of 20°C the maximum additional error is +/- 0.4% per 10°C of the span rising and falling.

Sensor Mechanism

 Bimetal coil, copper alloy bourdon
